Mobil-AC-Boy 1600-2.2, Mobile Power Supply, Construction & Emergency Power, UPS, Off-Grid System
A model of our innovative mobile power supply systems.
With the Mobil-AC-Boy, you can supply your desired devices anytime, anywhere.
The integrated battery inverter converts the energy from the built-in battery into pure sine wave AC power.
The Mobil-AC-Boy is a compact, rollable mobile power supply system (it is not a car trailer).
The housing is splash-proof – so it can also be used in the rain.
The 230-volt versions can be plugged into any standard Schuko socket for charging. The three-phase versions can be connected to 16 and 32 Ampere three-phase sockets.
Technical data for model 1600-2.2:
- Design, see photos.
- Effekta inverter with 1600 Watt continuous output.
- Max. peak load: 5 s at >150% load, 10 s at 110–150% load
- 2.2 kWh battery storage capacity at C10 (10-hour discharge time), 24 volts.
- Dimensions: L 880mm x W 580mm x H 885mm.
- Weight: 210 kg.
- UPS function.
- Sleep mode (standby) 2 watts.
- Energy-saving mode 10 watts.
- Normal operation 25 watts (without load).
- Integrated AC battery charger, charging power 600 watts.
- Integrated MPPT PV charge controller (PV modules not included!).
Standard Features:
1.
UPS function in all models. The Mobil-AC-Boy is also a mobile UPS system. This allows you to supply devices without interruption. If the power supply connected on the AC-IN side fails, the Mobil-AC-Boy switches seamlessly to battery operation. We can adjust your device to the desired backup time.
2.
Charging with renewable energy:
Standard on most models, with integrated MPPT PV solar charge controller. Versions for charging with wind or hydropower are also available on request.
3. Highest quality industrial-grade components.
Further information about this item:
Delivery time from receipt of a deposit: 2–4 weeks, as each Mobil-AC-Boy is custom-built for you.
You will receive an invoice with VAT shown, listing all components and services individually, as the Mobil-AC-Boy is offered by us as a kit, with assembly included.
For larger quantities, the price decreases!
With the Mobil-AC-Boy, you can supply your desired devices anytime, anywhere.
The integrated battery inverter converts the energy from the built-in battery into pure sine wave AC power.
The Mobil-AC-Boy is a compact, rollable mobile power supply system (it is not a car trailer).
The housing is splash-proof – so it can also be used in the rain.
The 230-volt versions can be plugged into any standard Schuko socket for charging. The three-phase versions can be connected to 16 and 32 Ampere three-phase sockets.
Technical data for model 1600-2.2:
- Design, see photos.
- Effekta inverter with 1600 Watt continuous output.
- Max. peak load: 5 s at >150% load, 10 s at 110–150% load
- 2.2 kWh battery storage capacity at C10 (10-hour discharge time), 24 volts.
- Dimensions: L 880mm x W 580mm x H 885mm.
- Weight: 210 kg.
- UPS function.
- Sleep mode (standby) 2 watts.
- Energy-saving mode 10 watts.
- Normal operation 25 watts (without load).
- Integrated AC battery charger, charging power 600 watts.
- Integrated MPPT PV charge controller (PV modules not included!).
Standard Features:
1.
UPS function in all models. The Mobil-AC-Boy is also a mobile UPS system. This allows you to supply devices without interruption. If the power supply connected on the AC-IN side fails, the Mobil-AC-Boy switches seamlessly to battery operation. We can adjust your device to the desired backup time.
2.
Charging with renewable energy:
Standard on most models, with integrated MPPT PV solar charge controller. Versions for charging with wind or hydropower are also available on request.
3. Highest quality industrial-grade components.
Further information about this item:
Delivery time from receipt of a deposit: 2–4 weeks, as each Mobil-AC-Boy is custom-built for you.
You will receive an invoice with VAT shown, listing all components and services individually, as the Mobil-AC-Boy is offered by us as a kit, with assembly included.
For larger quantities, the price decreases!
